Industrial Rugged 10.1 Inch Android Tablet PC Waterproof Tablet
LYA101K20 is a high-performance embedded integrated touch screen with the industrial core core Micro RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 10.1-inch LED LCD display (resolution of 1280 * 800) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS485, WIFI, BT interface, etc. It is suitable for industrial automation control, man-machine interface, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.
Specifications:
CPU processor:RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
Operating System:Android11.0/Ubuntu18.04/Linux 4.19
Running memory:2GB/4GB
EMMC:16GB/32GB/64GB/128GB
GPU:Mali-G52 1-Core-2EE
Size:10.1 Inch
Touch form:Capactive 10 touch
Product Performance
| | Performance | Detail |
| System | CPU processor | RK3568 / Cortex A55 4 core main frequency at 2.0GHZ |
| Operating System | Android11.0/Ubuntu18.04/Linux 4.19 |
| Running memory | 2GB/4GB |
| EMMC | 16GB/32GB/64GB/128GB |
| GPU | Mali-G52 1-Core-2EE |
| Display | Size | 10.1 Inch |
| Resolving power | 1920 * 1080 |
| Touch form | Capactive 10 touch |
| Luminance | 300 cd/ m² |
| Angle of view | Full perspective |
| Material | Material quality | Plastic face frame, metal back cover |
| Way to stall | Flat, outer, embedded |
| IP protection grade | Industrial grade IP65 dustproof and water proof (operating face) |
| Power | Power interface | 3 PIN*2.54mm terminal DC24V provides power supply |
| Power input | 12-30V Recommended value of 24V |
| Environmental Characteristics | Working temperature | -10℃ ~ 60℃ |
| Storage temperature | -20℃ ~ 70℃ |
| Operating humidity | 5-90 RH% |
| Serial port | 4*RS485 6-Road TTL serial port (reuse with serial port) |
| Audio interface | 1-way MIC interface |
| Gigabit Ethernet interface | 1 Route 10 / 100 / 1000 Mbps Ethernet port |
| HDMI interface | 1-Way HDMI output |
| TF | 1-Route TF card interface |
| SIM card | 1 Standard drawer-type interface with reserved eSIM interface |
| RTC | 1 Built-in supercapacitor |
| WIFI/BT | 2.4G WIFI / BT4.2 |
| MiniPCI-E 4G | MiniPCI-E 4G |
| GPIO | 4-way GPIO, IO direction is input and output configurable, and IO level is 5.0V； |
| USB2.0 | 1 Vertical plug interface USB 2.0,4 horizontal plug interface USB 2.0,1 built-in row pin (USB 2.0) |
| USB3.0 | 1 Vertical USB 3.0 (switch through dial switch) |
